Swept path

Our swept path analysis software solutions enable you to calculate vehicle paths precisely and efficiently, ensuring the safety and maneuverability of vehicles from passenger cars and 40-ton trucks to heavy-duty transporters. The calculations are performed within CAD software, allowing you to save all path data and visualizations in DWG format.

Generate Accurate Results Quickly

All necessary calculations are performed quickly and accurately by our software. The intuitive interface allows you to simulate various maneuvers effortlessly. Use standard vehicle libraries or create custom vehicles and configurations tailored to your needs.



Download a Demo



Key Features of Our Swept Path Analysis Software

  • Ease of Use: Simulate forward and reverse driving by simply dragging and clicking the vehicle, even for multipart configurations.
  • Dynamic Path Analysis: No need to draw guidelines manually. Start simulations immediately and adjust parameters on the fly. Instant feedback eliminates the need for post-analysis corrections.
  • Precision and Accuracy: Achieve optimal results by factoring in speed, steering times, and vehicle dynamics. Our turn radius calculator ensures reliable calculations.
  • Versatile Applications: Perform forward and reverse driving simulations, clearance analysis, collision checks, dynamic object binding, independent rear-axle steering, and more.
  • Vehicle Libraries: Use standard vehicles or create custom models, including trucks, buses, trailers, and heavy-duty transporters.
  • CAD Integration: Swept paths are calculated and visualized directly in CAD software, with results exportable in DXF or DWG formats. Ideal for vehicle tracking AutoCAD workflows.

Swept Path Analysis Software For International Use

Here are some examples of the added value our swept path analysis software offers for international use:



United States

Accurate truck turning radius CAD calculations and swept path analysis are crucial to ensure compliance with state-specific rules and avoid damage to infrastructure. Our software supports detailed planning for heavy-load transport through urban and rural environments, ensuring vehicles can safely navigate roads, intersections, and bridges.

Canada

The vast distances and varying terrains, especially in remote regions, require precise analysis to ensure maneuverability on both highways and local roads. Our software helps you assess route feasibility, particularly for timber and mining transport.

Australia

In Australia, heavy loads often need to traverse long distances through remote and challenging landscapes. Accurate turning radius calculation for trucks ensures safe navigation, especially in mining and agricultural regions. Our software supports dynamic simulations for complex vehicle configurations, including self-steering trailers.



United Kingdom

In the UK, narrow streets and historic infrastructure pose significant challenges for heavy transport. Our software helps planners ensure that trucks and buses can navigate tight turns and intersections safely, preventing infrastructure damage and optimizing logistics in urban areas. Use our truck turning radius calculator to ensure efficient planning.

France

French regulations emphasize protecting historical and urban infrastructure. Accurate swept path analysis ensures compliance with strict guidelines for oversized loads, particularly in dense city environments or near heritage sites. Our software enables precise route planning to avoid costly disruptions.

Sweden

Sweden’s forestry and logistics industries often require transporting large loads through forested and rural areas. Our vehicle simulation software helps optimize routes, ensuring vehicles can safely maneuver narrow roads, considering factors such as vehicle length and rear-axle steering.

Discover how our swept path analysis software can streamline your transport planning and improve safety.

Request a Demo now



Swept Path Analysis for Various Vehicles

With the vehicle library and editor, you can create swept paths for:

  • Passenger Cars, Vans, and RVs
  • Forklifts
  • Buses and Articulated Buses
  • 7.5-ton and 40-ton Trucks
  • 3-Axle Trucks and 12m Trucks
  • Semi-Trailers (e.g., 18m Rigs)
  • Low-Loaders
  • Garbage Trucks
  • Tractors with One or Two Trailers
  • Region-Specific Vehicles:
    • United States: School Buses, Fire Trucks
    • Canada: Logging Trucks, Snow Plows
    • Australia: Road Trains, Mining Vehicles
    • United Kingdom: Delivery Vans, Double-Decker Buses
    • France: Articulated Buses, Construction Vehicles
    • Sweden: Forestry Equipment, Articulated Trucks

Plan dynamic maneuvers such as 90-degree turns, 180-degree turns, reverse driving, and specific radius paths. Assess space requirements for entrances, parking lots, and garages with the help of our vehicle turning radius chart.



Request live presentation

Video: Construction of Junctions and Swept Paths

Specialized Swept Path Tools for Different Needs

smartTurn

Dynamic truck turning radius calculator for adjustable parameters related to speed, steering, and vehicle dynamics.

easyTrack

Developed in collaboration with GOLDHOFER AG, a world leader in heavy transport equipment, easyTrack is ideal for heavy-load transport. It allows for realistic simulation of complex configurations, including self-steering axles and specialized vehicles with unlimited width, length, or axle numbers. Features include:

  • Simulations even with limited digital map data.
  • Route simulations with internal or external guide points.
  • Freehand driving for forward and reverse maneuvers.
  • Automatic collision detection and marking in your CAD plan.
  • Creation of custom trailers and configurations, such as those used in wind turbine transport.

Key Functions at a Glance

  • Swept Path Calculation: Analyze maneuverability for intersections, roundabouts, loading docks, and more using our truck turn radius calculator.
  • Vehicle Library: Choose from standard models or create custom vehicles.
  • Maneuver Planning: Define routes or perform free simulations using keyboard controls.
  • Visualization: Integrate swept paths into your CAD plans.
  • Simulation and Animation: Save simulations and present animated vehicle movements.
  • Collision Detection: Identify collisions with road boundaries, trees, or other obstacles.
  • Realistic Dynamics: Account for real vehicle behavior, including acceleration and load shifts.

Support and Training

Our dedicated support team assists with installation and initial simulations. We provide a brief training session where you can address specific project challenges.

Download a Trial and boost your planning accuracy, safety, and productivity today!
